Description & Specifications
Our DS100A13 sprocket is a double single sprocket designed to drive two single strand #100 ANSI roller chains. It features 13 hardened teeth, offering exceptional wear resistance and ensuring a long service life. Manufactured from high-quality 1045CD steel, this sprocket is built for durability and reliability. Its plain stock bore design allows for easy customization, enabling users to machine it to their specific requirements.
DS100A13 Sprocket Dimensions
- ANSI Chain Size:100
- Bore (B):1"
- Tooth Count:13
- Pitch Diameter (PD):5.223"
- Outside Diameter (D):5.821"
- Sprocket Thickness (T):0.692"
- Hub Diameter (HD):3.781"
- Tooth Spacing (TS):2.000"
- Length Thru Bore (W):2.688"
- Material:1045CD
- Hardened Teeth:Yes (HRC 40-50)
- Type Of Finish:Black Oxide
All dimensions listed are nominal values.
